DESCRIPTION:

The STAIDTREAT® KITBOX 03.A (Active Speakers System), is an innovative modular acoustic treatment method, which combines with high quality performance speakers. The speakers are placed inside the absorbent boxes of the WBA/BXA models. This set of acoustics and public address devices is designed to aesthetically conceal acoustic treatment with speakers providing a good sound intelligibility, besides making technology imperceptible to eyesight. This system was essentially planned for 7.1 and 5.1 home-theatres surround systems, but it is also advisable for conference rooms, restaurants and bars, public spaces and for background music or speech purposes. It is composed by the two-way loudspeaker mounted inside the acoustic panel and by a self-amplified Subwoofer to be placed on the floor of the room. It has been created for small and mid-sized home-cinema rooms. It is a discrete system that combines acoustic treatment and the embedded speakers. The approach consists on adjusting the number of the modules to the room dimensions. All packs are supplied with assembly instructions, as well the necessary mounting accessories to apply the acoustic modules. Surround sound is the idea of engaging a listener in sound, just like a movie theater. Sound is half of the importance of the entertainment experience and the speaker placement is essential to experiencing the true impact of movies and music. A 7.1 surround system has seven discrete audio channels, Left, Right, Center, Left Surround, Right Surround, Left and Right Back, and of course, the Subwoofer.

Where to apply:

Rooms with an area between: 20 and 30 square meters.
Rooms with volumes between: 58 and 90 cubic meters.
For use in small and medium-sized home-theatre rooms, home-studios, Hi-fi rooms or instrument rooms.


Graphic

RT (s)
1,0
0,8
0,6
0,4
0,2
0

125 Hz
250 Hz
500 Hz
1 K
2 K
4 K


Freq (Hz)

Kit Box
Frequency
125Hz
250Hz
500Hz
1 Khz
2 Khz
4 Khz
RT60
03A
άs
0.27
0.23
0.28
0.28
0.26
0.27
0.27

Sabine: 0.27 sec


ACOUSTIC FEATURES:

Values were obtained by simulation in specific JAS® software and later confirmed through acoustic analyses in the rooms.
•The simulated and tested rooms are totally empty, there are only considered the revetment
materials and the acoustic panels.
•The simulated rooms were tested with all the materials and equipments shown in the images, and
the mentioned JOCAVI® KITBOX 03.A acoustic panels.

Traditional construction room with the following features:

Dimensions: (L,W,H): 4.90m / 3.60m / 2.80m.
Walls: masonry with painted fine stuff and a wooden door.
Ceiling: 12 mm - thick plaster.
Floor: natural floating parquet.

KIT BOX 03.A QUANTITIES:

Reference
Panels
Units
Diffuser
Absorbent
Tuned
BXA060
Staidtreat®BXA
10
-
-
V
BXW060
Staidtreat®BXW
34
-
-
V
WBA060
Staidtreat®WBA
31
-
V
-
BXA060A
Staidtreat®BXA Active
02
-
V
-
WBA060A
Staidtreat®WBA Active
06
-
V
-



STANDARD MINERAL GRANULATED COLOURS
* Included aluminium mounting accessories.
