Description
DESCRIPTION

The LOWNOTE C® is a low frequency membrane absorbent panel. It is designed to fit into 90˚ corners, and its available tuning frequencies are 50Hz, 63Hz and 80Hz with a range coverage of absorption approximately 1/3 octave above and below the tuning frequency.

It is developed to fine tune the modal distribution of small rooms such as studio control rooms and home theatres.

The principle used to develop LOWNOTE C® is the Helmholtz Resonator reasoning with a defined throat hole, through the use of an coloured engineered wood fibre board box with ABS velvet finishing as the front membrane, thus creating the tuned resonant chamber.

This model can be combined with LOWNOTE W® in order to boost bass absorption. Together these panels extend the range of the frequencies absorption to the next harmonic frequency. LOWNOTE C® it can be easily and quickly hung on any wall or ceiling 90˚ corner surface using the provided included accessories.

The LOWNOTE W® acoustic panel is a broadband low-frequency sound absorber designed to balance the modal distribution on small rooms like studios, music listening rooms, and home-cinemas.

The principle used to develop the LOWNOTE W® is the Helmholtz Resonator reasoning, through the combination of an coloured engineered coloured wood fibre board box with an ABS velvet finishing front membrane, which creates the tuned resonance chamber.

The dampening chamber system combined with the front concave shaped ABS membrane is able to offer a large range of bass control over several octaves, while not contributing to add mid/high frequency absorption.

This model can be combined with LOWNOTE C® in order to extend the absorption and fine tune the low end of the sound spectrum. These combinations lengthen the lower frequencies absorption to a homogenous absorption range. LOWNOTE W® panel can be easily hung on any wall or ceiling surface using the provided accessories. Panels can also be installed in a reinforced T-bar grid ceiling.

FEATURES
MODELS AND SIZES
LOWNOTE Wall® Tuned at 160Hz;
LOWNOTE Corner® available tuned to 50Hz, 63Hz or 80Hz., upon request.
Average absorption: 0.86/m2 [>50Hz;<250Hz]
Box made of engineered coloured wood fibre board
Front membrane made of ABS velvet finish
Fire-resistance: Bs1
Application on ceiling and wall

Package: 4 units
Installation: mounting accessories included
MODELS
HEIGHT
WIDTH
DEPTH
WEIGHT
LNW 060c
60 cm
60 cm
8 cm
5.2 Kg
LNW 060p
60 cm
60 cm
8 cm
5.2 Kg
LNC 060c
60 cm
60 cm
30 cm
7.2 Kg
LNC 060p
60 cm
60 cm
30 cm
7.2 Kg


MODELS AND SIZES
- LOWNOTE W® - walls & ceilings application

MODELS AND SIZES - LOWNOTE C®


ABSORPTION COEFFICIENTS - LOWNOTE W®
back to top

ABSORPTION COEFFICIENTS - LOWNOTE C®
back to top
Frequency [HZ]

ABSORPTION COEFFICIENTS SUMMARY

Frequency [HZ]
VELVETY FINISHINGS - front plate
RED
Flocked ABS
BLUE
Flocked ABS
GREY
Flocked ABS
BEIGE
Flocked ABS5
BLACK
Flocked ABS
White
Flocked ABS

ENGINEERED COLOURED WOOD COLOURS - box
BLACK
